| MODEL | DGC5205TS |
|---|---|
| Video Mode | TVI, CVI, AHD & CVBS switchable |
| Pick-up Element | 1/2.5 " CMOS image sensor |
| Number of Pixels | 2560 (H) x 1920 (V) |
| Video Frame Rate | 5MP@ 20fps |
| Min. Illumination | 0.1 Lux / F1.8, 0 Lux (IR LED ON) |
| S/N Ratio | More than 48dB (AGC OFF) |
| Shutter Speed | AUTO : 1/25(30)sec~1/50,000sec |
| Lens | f3.6mm / F1.8 |
| Lens Angle | 96° (Horizontal) / 50° (Vertical) / 116° (Diagonal) |
| IR LED | 2 units |
| IR Effective Distance | Up to 25 meters |
| IR Shift | YES |
| Day & Night Mode | YES |
| Noise Reduction | YES |
| IRIS Mode | AES |
| White Balance | AUTO |
| AGC | AUTO |
| Sharpness | Adjustable |
| Flickerless | 50HZ / 60HZ / OFF |
| BLC | Adjustable |
| DWDR | YES |
| IP Rating | IP66 |
| Operating Temperature | -20℃ ~ 40℃ |
| Operating Humidity | 90% or less relative humidity |
| Power Source (±10%) | DC12V / 0.5A |
| Current Consumption (±10%) | 100mA (IR lED OFF); 240mA (IR LED ON) |
| Net Weight (kg) | 0.32 |
